LPMS-CU: 9-Axis IMU / AHRS / Motion Sensor with CAN and USB Connectivity

Description

The LP-Research Motion Sensor CAN bus and USB version (LPMS-CU) is a miniature inertial measurement unit (IMU) / attitude and heading reference system (AHRS). The unit is very versatile, performing accurate, high speed orientation and displacement measurements. By the use of three different MEMS sensors (3-axis gyroscope, 3-axis accelerometer and 3-axis magnetometer) drift-free, high-speed orientation data around all three axes is achieved. The optional temperature and barometric pressure sensors allow accurate altitude measurements. The LPMS-CU can be connected to a host system either via a CAN bus or USB connection. Communication with high data transfer rates of up to 400Hz and internal sampling processing at 800Hz is possible. The LPMS-CU fits both machine and human motion measurements for size and cost sensitive applications.

Specifications

Communication interface CAN Bus, USB 2.0
Communication protocol LpCAN / CANOpen (CAN port), LpBUS (USB port)
Size 37 x 28 x 17 mm
Weight 12.8g
Orientation range 360° about all axes
Resolution < 0.05°
Accuracy < 2° (dynamic) < 0.5° (static)
Accelerometer 3 axes, ±20 / ±40 / ±80 / ±160 m/s2, 16 bits
Gyroscope 3 axes, ±250 / ±500 / ±2000 °/s, 16 bits
Magnetometer 3 axes, ±130 – ±810 uT, 16 bits
Pressure sensor (optional) 300 – 1100 hPa
Data output format Raw data / Euler angle / Quaternion
Data transmission rate up to 400 Hz
Power consumption 165 mW @ 5 V
Power supply 5 – 18 V DC
Connector Micro USB, type B
Case material Polyastyrol plastic
Temperature range – 40 to +80 °C
Software C++ library for Windows, Java library for Android, LpmsControl software and Open Motion Analysis Toolkit (OpenMAT) for Windows.

Order

Product Package contents Price
LPMS-CU 1 x LPMS-CU sensor (standard casing)
1 x Micro USB cable
1 x User guide card
1 x Warranty service (1 year)
Contact us
Find a distributor
LPMS-CU OEM 1 x LPMS-CU mainboard
1 x CAN and USB communication board
1 x User guide card
1 x Warranty service (1 year)
Contact us
Find a distributor
